Feature：

Full band、One click decoding、Frog chirping at the end、USB Charging、Chinese/English input、Flash Light function、Radio  function、AM aviation reception、Frequency: Full band:136-520MHZ、128 Storage、Chinese/English language prompts、Radio  function、Wide/Narrow band、Interference frequency more confidential call、Auto power-saving、Special signaling(frequency hopping)、VOX Make calls without pressing the PPT

GENERAL：
Frequency：136-520MHz
Storage：128个
Channel space：25KHz/12.5KHz
Input voltage：7.4VDC
Battery capacity：6000mAh
Battery life：About 14 Hours
Standby：≤65mA
Receiver：≤450mA
Transmitter：≤1.8A@High power，650mA@Low power
Frequency stability：±2.5ppm
Work temperature：-30℃to+60℃
Antenna impedance：50Ω
Size：121X61X33mm
Weight：220g

TRANSMITTER：
Receiver sensitivity：0.25μV（12dB SINAD)
Adjacent channel selectivity：≥60dB@25KHz，≥55dB@12.5KHz
Adjacent channel selectivity：≥60dB@25KHz，≥55dB@12.5KHz
conducted spurious emission：≤-57dB@25KHz，≤-57dB@12.5KHz
SNR：≥45dB@25KHz，≥-40dB@12.5KHz1W@16ohms
Audio output power：≤5%
Radio distortion：+1~-3dB
Audio response（300-3000Hz）：+1~3dB

RECEIVER：
Transmissiom output power：≤10W
Modulation：16K0F3E@25KHz，11K0F3E@12.5KHz
Spurious emission：-36dBm＜1GHz，-30dBm＞1GHz
SNR：45dB@25KHz，40dB@12.5KHz
Radio distortion：≤5%
Modulation limited：±5.0KHz@25KHz，±2.5KHz@12.5KHz
Adjacent Channel Power：70dB@25KHz，60dB@12.5KHz
Audio response（300-3000Hz）：+1~3dB
